Detta är hur ”tråckelramen” jag använder för mina ”handdukshängare" ser ut. I princip är det bara några raksömslinjer.
- för placering
- för att hålla handduken på plats under brodering
- för att markera var övre kanten av handduken ska placeras
- för att hålla bandet/hängaren på plats under brodering
This is how the "frame of basting stitches" I use for my “Towel Holders” look like. Basically there are just some lines.
- for placement
- to keep towel in place during embroidery
- to mark where the top of the towel is to be placed
- to hold the ribbon in place during embroidery
Detta är den färdiga skissen av den stygnsatta ”tråckelramen”. Jag kommer visa steg för steg hur man gör denna "tråckelram".
This is the finished sketch of the digitized "basting frame". I will however show you step by step how you make it.
Gör så här:
-Du kommer bara att använda ”running stitches” (raksömsstygn) med en stygnlängd på 6 millimeter så att de lätt kan tas bort när broderiet är klart.
-Jag rekommenderar också att använda olika färger på tråden för varje moment i denna design.
-Ställ in rutnätet (grid) i Embroidery Software till 10 millimeter, det blir så mycket enklare eftersom du kommer att ha ett verktyg för att mäta längden på linjerna då.
-Ta hjälp av de horisontella och vertikala mittenlinjerna när du mäter de olika stegen.
-Använd en broderbåge som är 100x100 millimeter och designen blir då cirka 80x80 millimeter eller en 120x120 millimeter broderbåge som kommer att motsvara en design med en storlek på cirka 100x100 mm
Proceed like this:
-You will only use running stitches with a stitch length of 6 millimetres so that they will be removed easily when the embroidery is finished.
-I also recommend using different colours of thread while digitizing each step of this frame.
-Set the grid in your software to 10 millimetres, it will be so much easier as you will have a tool for measuring the length of the lines then.
-Use the middle horizontal and vertical lines as help to measure the steps.
-Use a hoop that is 100x100 millimetres and the design will then be approximately 80x80 millimetres or a 120x120 millimetres hoop which will correspond to a design size of approximately 100x100 millimetres.
I bilderna nedan har jag använt en 100x100 mm broderbågeIn the below pictures I have used a 100x100 millimetres hoop.
Step 1
Colour 1
Line A - B
Börja med att stygnsätta en rak linje av “running stitches” (raksöms stygn) – 10 mm från toppen av broderbågens yta och 10 mm från varje sida. Linjen kommer då vara 80 mm lång.
Start by digitizing a line of running stitches - 10 millimetres from the top of the hoop and 10 millimetres from each side. The line will then be 80 millimetres long.
Step 2
Colour 2
Line B - E
Gör en linje av “running stitches” (raksöms stygn) – från B till C. Stanna när du är 10 mm från botten av broderbågens yta. Linjen är då 80 mm.
Vänd 90 grader till vänster och fortsätt med “running stitches” (raksöms stygn) 80 mm från C till D.
Sen blir det ytterligare en 90 gradig vändning och fortsätt 70 mm upp mellan D och E även här med “running stitches” (raksöms stygn). Det ska vara ett 10 mm mellanrum mellan E och A) (vilket motsvarar de två översta horisontella linjerna).
Make a line of running stitches down from B to C. Stop when you are 10 millimetres from the bottom of the hoop. The line is then 80 millimetres.
Turn 90 degrees to the left and go 80 millimetres from C to D.
Then a 90 degree turn again up from D to E, but this time you will only go 70 millimetres, so there will be a gap between E and A of 10 millimetres (which will be the two top horizontal lines).
Step 3
Colour 3
Line E – J
Detta steg är linjen som fäster ovandelen av handduken likväl som handdukshängaren.
This is the final step that will fasten the top of the towel as well the ribbon. I will show this step in a couple of pictures.
Gör en linje av “running stitches” (raksöms stygn) – från E till F – 50 mm åt höger.
Make a line of running stitches from E to F - 50 millimetres to the right.
Gör en linje av “running stitches” (raksöms stygn) – från F till G – 20 mm diagonalt nedåt vänster.
Make a line of running stitches from F to G - 20 millimetres diagonally down to the left.
Gör en linje av “running stitches” (raksöms stygn) – från G till H – 20 mm åt höger.
Make a line of running stitches from G to H - 20 millimetres to the right.
Gör en linje av “running stitches” (raksöms stygn) – från H till I – 20 mm diagonalt upp åt vänster.
Make a line of running stitches from H to I - 20 millimetres diagonally up to the left.

Slutligen - gör en linje av “running stitches” (raksöms stygn) – från I till J – 50 mm åt höger.
Finally make a line of running stitches from I to J - 50 millimetres to the right.
Alternative in digitizing the basting frame
Man kan utesluta momentet med “X” i mitten av den andra linjen från toppen. Visserligen kommer inte hängaren ligga på plats lika säkert under brodering men om man exempelvis använder en applikation som design -så täcks ju ändarna av tyget.
There is however an option to omit the “X” in the middle of the second top line, the ribbon will not be as secured as in the first design during
embroidery but it is possible if you, for example, use an appliqué design where the ends will be covered.
Vad man gör är att man utesluter stegen F – G - H och I och gör en linje av “running stitches” (raksöms stygn) direkt från E till J.
What you do is that you just omit the steps involving F – G - H and I and go directly from E to J with a line of running stitches.
I min nästa blog ska jag visa:
-hur man kombinerar och placerar designen i broderbågen
-hur man placerar och fäster hängaren
-hur det hela sys på handduken och hur den placeras i bågen
In my next blog I will show you:
-how to combine the basting frame and the design in the hoop
-how to place and fasten the ribbon
-how to place and embroider the towel in the hoop.
